See crystal clear images with this high-resolution WiFi Dome-style CCTV camera. It comes with two-way audio capability, allowing you to hear and talk to anyone at your home anytime, anywhere. And with its intelligent motion tracker, you can keep track of any movement in your household by getting alert notifications.
FEATURES
- High-quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- Clear imaging against strong back light due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- High-quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP67)
SPECIFICATION
Camera
Image Sensor: 2 MP CMOS
Max. Resolution: 1920 (H) × 1080 (V)
Min. Illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night: 24/7 Color Imaging
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Signal System: PAL/NTSC
Slow Shutter: Max. 16 times
Lens
Lens Type: 2.8 mm, 3.6 mm fixed focal lens
Focal Length & FOV: 2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116° 3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
Image Settings: Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Smart Light, Anti-Banding, AGC
Day/Night Mode: Color
Wide Dynamic Range (WDR): ≥130 dB
Image Enhancement: WDR, BLC, HLC, Global, HLS
Privacy Mask: 4 programmable privacy masks
Noise Reduction: 3D DNR/2D DNR
White Balance: Auto/Manual
Interface
Video Output: Switchable TVI/AHD/CVI/CVBS
Alarm: Solid Light Alarm (White Light)
Audio: Built-in mic
Event: Motion Detection
Power: 12 VDC ± 25%, max. 4.2 W
*You are recommended to use one power adapter to supply the power for one camera.
Material: Plastic
Dimension: 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76")
Weight: Approx. 223 g (0.49 lb.)
Operating Condition: -40°C to 60°C (-40°F to 140°F), humidity: 90% or less (non-condensing)
